CAD Modeling

Westerhold Labs uses SolidWorks for CAD modeling.

We have experience with many of the complex features of SolidWorks including assemblies, design tables, configurations, and simulations. This allows us to efficiently model parts and assemblies to meet your requirements. Before we begin any CAD modeling we will review your requirements. We will make you aware of any design elements that may increase cost, hinder part manufacturability, or introduce unnecessary risk.

Wizard Deluxe Oscillating Fan Gear

CAD for a Wizard Deluxe oscillating fan gear. Used in the fan's oscillation transmission.

Craftsman Table Saw Crank Handle

CAD for a Craftsman table saw crank handle. Used to raise and lower the blade on a Craftsman table saw.

DeWalt Flexvolt Battery Adapter

CAD for a DeWalt Flexvolt battery adapter. Used to interface with DeWalt 20V/60V Flexvolt batteries.

Custom Fixture Plate

CAD for a custom fixture plate. Used to precisely position work pieces on a milling machine.

Turner's Cube

CAD for a Turner's cube. Used as a test part for machinists and for decoration.

Injection Mold Assembly

CAD for an injection mold assembly. Used to make plastic parts.

Injection Mold Base, "A" Side

CAD for an injection mold base, "A" side. Used to hold one side of a cavity insert to make plastic parts.

Injection Mold Base, "B" Side

CAD for an injection mold base, "B" side. Used to hold one side of a cavity insert to make plastic parts.

Injection Mold Ejector Pin Base Plate

CAD for an injection mold ejector pin base plate. Used to hold ejector pins as part of an injection mold assembly.

Injection Mold Ejector Pin Retainer Plate

CAD for an injection mold ejector pin retainer plate. Used to hold ejector pins as part of an injection mold assembly.
